excavator joystick

FOB Reference Price:Get Latest Price
$650.00 - $700.00 / Piece | 1 Piece/Pieces (Min. Order)
Compatible Brand:
Report Suspicious Activity
Quick Details
Brand Name:
1 year
After-sales Service Provided:
Online support
Applicable Industries:
Machinery Repair Shops, Manufacturing Plant, Farms, Retail
color: black
function:spring return
service Life: long life-time
For hoist crane
For car loader
For forklift
For excavator
work high above the ground platform
For tractor,harvester and so on
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
1. 1pc per inner box
2.50pcs per carton
3.100pcs per carton
4. As customer's requirement
Ningbo or shanghai

OM3000B-2AC-NA-MS12-B0018 two buttons





Product characteristic:

Conforms to the modern man-machine engineering principle, specially for project mechanical profession design use.
The disposition has the non-contact Hall sensor and the long life potentiometer two kind of angular displacements detect method could choose.
Has many kinds of different type handle top port to supply choice, simultaneously, button quantity and the position also have the different disposition form.
The joystick’s output signal could be potentiometer output, the Hall voltage output, the CAN bus output, as well as a variety of standard analog signals

Application scope:

This series products mainly apply in hoist crane, car loader, forklift, excavator, work high above the ground platform, tractor, harvester and so on.


Technical parameter:

Mechanical parameter:
Starting operation strength:15N
Biggest operation strength (limiting position):30N
Limit permission operation strength:300N
Operation angle:±20°
Service life:

Is bigger than 5,000,000 times (potentiometer type),

is bigger than 10,000,000
times (Hall type)

The weight:475g (without top port)
Electrical parameter:
Potentiometer type:
Total resistance value:5KΩ or 10KΩ
Electric angle:±18°
Output voltage scope (relative power supply voltage):0~100%; 10~90%; 25~75%
The median position voltage (relative power supply voltage):48%~52%
The median position dead zone angle:±2.5°
The potentiometer loads max voltage:DC32V

Potentiometer allows the maximum power consumption (25


Direction switch: Load capacity: 10mA@30Vdc (resistive load)
Outset angle: ±3°~±5°
Micro switch: Load capacity:3A@250Vac, 4A@30Vdc (resistive load)
Mechanical life:30,000,000 above
Electrical life:more than 200,000 times
Insulation resistances:more than 100MΩ (500Vdc insulation resistance meter)
Hall type:
Power supply voltage:5±0.5Vdc
Power source consumption electric current:6.5mA (single axis, 1 Hall sensor)
13mA (single axis, 2 Hall sensors, or, double axis, 1 Hall sensor)
26mA (double axis, 2 Hall sensors)
Limit permission overvoltage:30Vdc (continuous use)
The reverse limit permits the voltage:15Vdc
Output voltage scope (optional):H51= Hall type, DC5V power source, 0.5V~2.5V~4.5V voltage output
H52= Hall type, DC5V power source, 0V~2.5V~5V voltage output
H53= Hall type, DC5V power source, 1.25V~2.5V~3.75V voltage output
H54= Hall type, DC5V power source, 1.0V~2.5V~4.0V voltage output
Minimum load impedance: 5KΩ
Insulation resistance: Is bigger than 50MΩ (when 500Vdc)
With conversion circuit:
With power supply voltage scope:18~36Vdc(DC24V) 9~18Vdc(DC12V)
Power source consumption electric current:<20mA
Maximum output electric current:10mA
Note: The voltage type output already isolates completely the output port and the power source
Standard voltage output:
Output voltage scope (optional):

U21=DC24V power source, - 10V~0V~+10V voltage output

U22=DC24V power source, +10V~0V~+10V voltage output

U23=DC24V power source, - 5V~0V~+5V voltage output

U24=DC24V power source, +5V~0V~+5V voltage output







Express delivery:




1. Samples time: Need 7-10 days to preparing the samples after receiving the payment.

2. Samples payment term: T/T, PAYPAL, Western union


Quality Guarantee:

1.Strictly quality control  before leave factory

2. Quality guarantee  within one year



1.Low MOQ: 1PC

2.New design Accepted: As your requirement

3.Good Service: Customer as God

4.Good Quality: Strict quality control  and good reputation

5.Fast & Cheap Delivery: Big discount from express agent (Long-term Contract)


Order Guide:

1. Inquiry-Professional quotation.
2. Confirm the price, lead time, packing requirement, payment term etc.
3. OMTER sales send the Proforma Invoice with OMTER seal.
4. Customer make the payment and send us Bank receipt.
5. Will inform client that we have got the payment, arrange the production & inform the estimated time.
6. After delivery will inform the tracking number and check the status for clients.
7.   Feedback to TALL about Quality , Service, Market Feedback & Suggestion. And we can do better .
